Shacman 380HP 6x4 Dump Truck - Engineered For Extreme Mining & Rock Hauling
Shacman_Dump_Truck_Front_Axle_and_Suspension
Shacman_Dump_Truck_Hydraulic_Oil_Tank_for_Lifting
Shacman_Rear_Heavy_Axle_Tires_and_Mudguard
Shacman_Tipper_Steering_Wheel_and_Driver_Console
Shacman_Tipper_Truck_Cab_Side_and_Steps
Shacman_Truck_Cab_Interior_Dashboard_and_Sleeper
Shacman_Truck_Engine_Block_and_Frame_Detail
Shacman 380HP 6x4 Pob Tseg Truck - Engineered Rau Kev Tshaj Tawm & Pob Zeb Hauling
Hom Tsav:
6 × 4 (Dual Drive rear qag)
Cav Hom:
WP12.380, 380HP Fais fab tso zis
Maximum Torque:
1250 N·m
Rated Loading Peev Xwm:
30 Tons
Dumper Box Dimension:
5600 × 2300 × 1500 hli
Dumper Box Peev Xwm:
19.32 cbm (kub)
Xim xaiv:
Raws li Customized (txiv kab ntxwv, dawb, daj, thiab lwm yam)
Shacman 6x4 Tipper: Cov txheej txheem ceev & Cov yam ntxwv tseem ceeb
Niaj hnub nimno engineering xav tau uncompromising durability, thiab covShacman 6x4 Heavy Duty Tipper(SX3255DT384R) yog tsim los xa. Tsim los ntawm lub siab -torque 380HP WP12 lub cav thiab qhov tseeb- sib tw 12TDS2010 kis tau tus mob, lub tsheb tsim khoom no siv zog tswj 30-tuj payload hla cov av xoob lossis tsis ruaj khov. Featuring ib qho kev cuam tshuam -tiv thaiv dumper lub thawv nrog 8mm hnav- phaj pem teb thiab kev sib xyaw pem hauv ntej- nqa cov tshuab, nws yog qhov kawg qis-cov cuab yeej tu vaj tse rau cov chaw ua haujlwm siab.
Uncompromising Powertrain & High Gradeability
Ntawm lub hauv paus ntawm lub tshuab lies lub siab -efficiency WP12.380 lub cav, tsim ib tug commanding 1250N·m torque nkhaus. Lub tshuab hluav taws xob no tshwj xeeb tshaj tawm rau cov chaw txua txiag zeb thiab cov chaw ua haujlwm hauv av nkos, ua kom lub tsheb khaws cia siab tshaj plaws uas tsis muaj roj ntau dhau. Lub multi-ceev 12TDS2010 phau ntawv kis tau tus mob optimizes cav fais fab tso zis rau txhim khu kev qha hla-lub teb chaws mus.
- Lub cargo lub cev yog ib tug qauv fortress, optimized rau poob loj -boulder pob zeb thiab abrasive mining khib nyiab. Tsim los ntawm siab -yield tensile steel, lub thawv 19.32 cbm nta 8 hli puag phaj thiab 6 hli sab nraub qaum los tiv thaiv hauv zos deformation. Qhov hnyav -lub luag haujlwm pem hauv ntej- nqa hydraulic ram yog qhov chaw rau kev ua kom pom tseeb, ua kom nrawm dua, huv dua- voj voog nyob rau hauv tag nrho 30-tuj payloads.
-
Lub chassis yog anchored los ntawm ib tug siab -clearance HANDE MAN 9.5T pem hauv ntej steering qag thiab dual HANDE MAN 16000Kg ob - txo rear tsav qag khiav ib tug hnyav -duty 5.92 iav piv. Qhov kev teeb tsa kev siv tshuab no sib npaug faib cov khoom ntsug hnyav thaum tus qauv 12.00R20 radial log tsheb tiv thaiv lub qag sib dhos los ntawm kev sib tsoo hnyav thiab qhov phom sij txaus ntshai nyob rau hauv ntse - pob zeb ib puag ncig.
Fatigue- Ib puag ncig tus neeg ua haujlwm pub dawb
Kev hloov chaw ntev yuav tsum muaj chaw ua haujlwm txhawb nqa. Lub F3000 nruab nrab-ntev ca cabin txuas nrog lub suab nrov nrov rwb thaiv tsev thiab thaj chaw pw tsaug zog rau kev tos tos. Ua ke nrog kev tswj hwm ergonomic layout thiab ZF-tech 8098 hydraulic zog steering, tus neeg tsav tsheb tau ntsib cov lus taw qhia steering thiab kev ntxhov siab ntawm lub cev tsawg, ncaj qha nce qhov chaw nyab xeeb thiab cov khoom tsim tawm txhua hnub.
Cov duab ntxaws
|
Technical Parameter |
Specifications Paub meej |
|
Yam khoom qauv |
SX3255DT384R |
|
Tsav hom |
6 × 4 (Dual Drive rear qag) |
|
Hom cav |
WP12.380, 380HP Fais fab tso zis |
|
Maximum Torque |
1250 N·m |
|
Rated Loading Capacity |
30 Tons |
|
Dumper Box Dimension |
5600 × 2300 × 1500 hli |
|
Dumper Box Volume |
19.32 cbm (kub) |
|
Dumper Box Thickness |
Hauv qab: 8mm|Sab & Back: 6mm |
|
Lifting System |
Pem hauv ntej Lift System |
|
Kev sib kis |
12TDS 2010 + PR101 Gearbox |
|
Pem hauv ntej qag Spec |
HANDE MAN 9.5 Tons Hnyav plaub ntug qag |
|
Tsheb Axle Spec |
HANDE MAN 16000Kg × 2 Ob Chav Txo Tsav Qag (5.92 Ratio) |
|
Steering System |
ZF Technology 8098 Fais Fab Steering |
|
Tyre Specification |
12.00R20, Premium Radial Tyres |
|
Cabin Architecture |
F3000 Nruab nrab -Length Flat Cabin |
|
Zuag qhia tag nrho Dimensions |
8500 × 2500 × 3400 hli |
|
Xim Fleet Options |
Raws li Customized (txiv kab ntxwv, dawb, daj, thiab lwm yam) |
Ntim & Shipping
Cov lus teb rau cov neeg siv khoom
FAQ
Q: 1.Peb yog leej twg?
A: YALONG'S lub hauv paus chaw haujlwm nyob hauv Shandong, Suav. Txij li xyoo 2018, peb tau muag rau Africa (30.00%), South Asia (20.00%), Southeast Asia (20.00%), Middle East (20.00%), thiab kev lag luam hauv tsev (10.00%). Muaj li ntawm 11-50 tus neeg nyob hauv peb lub hoobkas.
Q: 2.Vim li cas koj yuav tsum yuav los ntawm peb tsis yog los ntawm lwm tus neeg muag khoom?
A: Peb ua raws li kev lag luam lub tswv yim ntawm "zoo ua ntej, cov neeg siv khoom ua ntej" thiab tau txais kev ntseeg siab thiab kev txhawb nqa ntawm cov neeg siv khoom hauv tsev thiab txawv teb chaws nrog cov khoom zoo, kev pabcuam zoo, thiab cov nqi muag khoom tsim nyog. Lub teb chaws xa tawm tseem ceeb thiab cheeb tsam yog: Africa, Southeast Asia, Central Asia, South America thiab lwm qhov chaw. Peb muaj cov kws tshaj lij tsim thiab tsim pab pawg uas tuaj yeem tsim thiab tsim lub tsheb uas tsim nyog rau koj raws li koj xav tau; nplua nuj export kev, paub txog cov txheej txheem export thiab yuav tsum tau ntawv pov thawj ntawm ntau lub teb chaws, thiab tuaj yeem xa koj lub tsheb rau koj sai dua; Peb Nrog thawj - cov cuab yeej tsim khoom hauv chav kawm, cov cuab yeej muaj zog thiab cov txheej txheem kev sim siab, peb tuaj yeem muab cov tsheb ruaj khov thiab txhim khu kev qha rau koj.
Q: 3.Peb tuaj yeem lav qhov zoo?
A: Ib txwm ua ntej- qauv tsim ua ntej ntau lawm; Ib txwm soj ntsuam zaum kawg ua ntej xa khoom;
Q: 4.Vim li cas koj yuav tsum yuav los ntawm peb tsis yog los ntawm lwm tus neeg muag khoom?
A: YALONG yog ib lub tuam txhab tshwj xeeb hauv kev xa tawm cov tsheb thauj khoom siv, muab ib qho kev pabcuam - nres xws li kev yuav khoom, kev npaj, tshuaj xyuas, tshaj tawm kev lis kev cai, kev thauj mus los, thiab kev lis kev cai ntawm qhov chaw rau kev lis kev cai txawv teb chaws.
Cim npe nrov: Shacman 380hp 6x4 pob tseg tsheb - engineered rau huab mining & pob zeb hauling, Tuam Tshoj shacman 380hp 6x4 pob tseg tsheb - engineered rau huab mining & pob zeb hauling manufacturers, lwm tus neeg
